Countersunk head tubular rivet
|
Material
- Head
- AluminumStell
- Mandrel
- StellStell
| D | Hole Size | Head Thick (MM) | L (MM) | Surface Diameter (MM) | Thick (MM) |
|---|---|---|---|---|---|
| ø2.4 | ø2.5~2.6 | 0.5~10 | 1.5~6.0 | 3.8~5.4 | 0.55 ~0.7 |
| ø3.2 | ø3.3~3.4 | 1.0~6.1 | 1.7~6.5 | 4.8~6.4 | 0.6~1.0 |
※The suggested length is head thick +(0.4~0.8mm)
